Extra footprint, lower ground pressure. Wider shoulders and deeper grooves give superior flotation on soft or muddy sites.
Heavy-duty carcass moves up to 12 500 kg @ 10 km/h (23.5-25, 24-ply) while silica-reinforced rubber fights heat and cuts.
Comprehensively approved (GCC/GSO, SASO, SONCAP, ECE, DOT) and pairs perfectly with W3 for a complete loader line-up.
| Size | PR | Overall Diameter (mm) | Section Width (mm) | Rim | Max Load (kg) @ 10 km/h | Max Load (kg) @ 50 km/h | Inflated Pressure (kPa) @ 10 km/h | Inflated Pressure (kPa) @ 50 km/h | Pattern |
|---|---|---|---|---|---|---|---|---|---|
| 23.5-25 | 20 | 1 615 | 595 | 19.50/25 | 10 900 | 7 300 | 375 | 300 | E3/L3 (W4) |
| 23.5-25 | 24 | 1 615 | 595 | 19.50/25 | 12 500 | 8 000 | 475 | 50 | E3/L3 (W4) |
